PRODUCT DISCONTINUATION Last order: 2015/12/1 Last delivery: 2016/6/1 DISCONTINUED NEW (REPLACEMENT) Device Module Device Module 12MS06012L43G24965 6MS24017E33G32859 12MS06012L43G29811 6MS24017E33G32859 12MS08012E33G30961 6MS24017E33G32859 12MS08012E33G32628 6MS24017E33G32859 12MS08017F63G22902 6MS24017E33G32859
